8 2
T H E B U I L D I N G C O N S E R VAT I O N D I R E C T O R Y 2 0 1 4
T W E N T Y F I R S T E D I T I O N
3.1
STRUCTURE & FABRIC :
ROOFING
ROOF LIGHTS
Our Heritage Lead Covered Steel Patent Glazing Bar is a unique product
that encapsulates the very essence of the Patent Glazing tradition, the design
originating from Victorian enterprise and ingenuity.
The glazing bar consists of a rolled mild steel core with a minimum tensile
strength of 355 N/mm
2
. The core is sprayed with a proprietary rust inhibitor
before being inserted into its cover, a seamless lead extrusion that incorporates
a twin wing weathering system and glass seatings. The ends of the cover are
soldered to give a hermetic seal. Cast brass fixing plates and glass stop are
screwed on to produce the finished glazing bar.
The Heritage Lead Covered glazing bar range meets all the requirements of
British Standard BS 5516 1991 and is ideally suited to replacement, refurbishment
and upgrading of prestigious projects and for modern glazing schemes where
traditional materials are appreciated.
Tel 01924 461213
Fax 01924 458083
The Standard Patent Glazing Co. Ltd
Flagship House Forge Lane Dewsbury
West Yorkshire WF12 9EL
the original patent glazing bar
perfect for listed and historic buildings
manufactured to original specification for over 100 years
traditional cast brass furniture
hermetically sealed ‘Heritage’
lead covered steel glazing bar
supporting structural rail
glazed infill
(single and double glazed
options available)
Cast brass glazing
bar stop
Botanical Gardens ~ Sheffield
◾
◾
LUMEN ROOFLIGHT
RMD 1, Dobles Lane Industrial Estate, Holsworthy EX22 6HL
Tel 0330 300 1090
Email
ROOFLIGHTS
: The Lumen range of rooflights includes designs for
conservation and contemporary projects for both pitched and flat roof
applications. Lumen rooflights are manufactured to an industry leading
standard and incorporate a wide range of Pilkington glazing, including
self clean Activ. Manufactured in the UK to ISO9001:2008 and available
in a range of standard or bespoke sizes.
THE BUILDING
CONSERVATION
DIRECTORY
Will you be in it?
Contact Cathedral Communications for more
subscriptions
advertising
